Motherboards Tyan

1S AMD EPYC Genoa CPU CEB Form Factor 8 DIMM slots w/ DDR5 4800 memory support Up to 12 SATA ports 5 PCIe 5.0 x16 slots 2 MCIO 8x & 2 MCIO 4x conn. (NVMe) 2 NVMe M.2 22110 / 2280 slots 2 10GBase-T + 2 1000Base-T LAN + 1 dedicate 1000Base-T IPMI ports AST2600 BMC with IPMI 2.0 & Redfish support

1S AMD EPYC Genoa / Bergamo / Genoa X CPU CEB Form Factor 8 DIMM slots w/ DDR5 4800 memory support Up to 12 SATA ports 5 PCIe 5.0 x16 slots 2 MCIO 8x & 2 MCIO 4x conn. (NVMe) 2 NVMe M.2 22110 / 2280 slots 2 1000Base-T LAN + 1 dedicate 1000Base-T IPMI ports AST2600 BMC with IPMI 2.0 & Redfish support

SSI CEB form factor and optional dual port Intel X550 10GBase-T Ethernet. Intel Ice Lake SP Xeon Processor with TDP up to 270W Chipset Intel C621A PCH Memory (8) DDR4 DIMM slots (8 memory channels) Supporting up to 2TB RDIMM/LRDIMM DDR4-3200 PCIe Expansion Slots Slot 1: PCIe Gen 4.0 x0 or x8 (MUX with Slot 2) Slot 2: PCIe Gen 4.0 x16 or x8 (MUX with Slot 1) Slot 3: PCIe Gen 4.0 x4 Slot 4: PCIe Gen 4.0 x16 Slot 5: PCIe Gen 4.0 x16 Network (2) 10GBase-T LAN Ports (Intel X550-AT2) (Optional) (1) 10

Dual LGA 1366 Intel 5520 12 x 240pin

Dual LGA 771 Intel 5000V SMSC SCH5017 Super I/O chip 6 x 240Pin

Dual 479 Intel E7520 8 x 240Pin

Dual mPGA604 Intel E7320 SMSC DME1737 LPC super I/O chip 6 x 240Pin

Dual 1207(F) NVIDIA nForce Professional 3600

Dual 940 AMD 8131 Analog Devices ADM1027 Hardware Monitoring IC 8 x 184Pin

939 NVIDIA nForce4 Professional 2200 SMSC DME1737 4 x 184Pin

Interloper Part #:109552 Form Factor:ATX Socket Type:Socket 604 Compatible CPU Brand:Intel

Dual mPGA604 Intel E7501 Winbond W83627HF Super I/O chip Winbond W83782D hardware monitoring chip 6 x 184Pin

Tyan S2720U3GN-533 Thunder I7501 Dual Xeon Socket-604 U320...

1S AMD Siena CPU 12' x 9.6' ATX Form Factor 8 RDIMM slots with DDR5-4800 memory support 4 PCIe 5.0x16 slots 2 MCIO 8x + 2 MCIO 4x conn. (NVMe) 2 NVMe M.2 22110 / 2280 slots 2 10GBase-T + 2 1000Base-T LAN + 1 dedicate 1000Base-T IPMI ports AST2600 BMC with IPMI 2.0 & Redfish support

CPU: Installed 2X AMD Epyc Milan 7713, 64 cores, 128 threads, 256MB cache, 2.0GHz, 225W. Memory (16) DDR4 DIMM slots (16 memory channels) Supporting up to 4TB RDIMM/LRDIMM/NVDIMM DDR4-3200 Maximum memory speed subject to AMD memory controller limitations, DDR4-3200 not available in all configurations or capacities. 4TB capacity not yet tested. PCIe Expansion Slots (3) PCIe Gen 4.0 x16 slots (1) PCIe Gen 4.0 x8 slot (1) PCIe Gen 4.0 x32 slot designed for riser card deployment Network (2) 1000Base

CPU: Installed 2X AMD EPYC 7252, 8 cores, 16 threads, 3.2G, 120W. AMD 'Rome' Platform based on the EPYC 7003/7002 processor. Features support for PCIe Gen 4.0, DDR4-3200, and CPU TDP up to 280W all in a 12x9.8' ATX form factor. Low loss PCB & no PCIe redriver/retimer chips for a low cost PCIe Gen 4.0 solution. AMD EPYC 7002 and 7003 Processor /w TDP up to 280W Memory (8) DDR4 DIMM slots (8 memory channels) Supporting up to 2TB RDIMM/LRDIMM/NVDIMM DDR4-3200 PCIe Expansion Slots (5) PCIe Gen 4.0 x

Motherboard with Single-socket Intel Sapphire Rapids Xeon processor in an SSI-CEB form factor. Support for up to two double-wide GPU accelerator cards. Intel Sapphire Rapids-SP Processor with TDP up to 350W Chipset Intel Emmitsburg C630-Series PCH Memory (8) DDR5-4800 DIMM slots (8 memory channels) Supporting up to 4TB RAM (Assuming 8x512GB DIMMs) 512GB DIMM support is stretch goal but may not be validated until requested PCIe Expansion Slots (4) PCIe Gen 5.0 x16 slots (All lanes from the CPU so

Motherboard with Single-socket Intel Sapphire Rapids Xeon processor in an SSI-CEB form factor. Support for up to two double-wide GPU accelerator cards. Intel Sapphire Rapids-SP Processor with TDP up to 350W Chipset Intel Emmitsburg C630-Series PCH Memory (8) DDR5-4800 DIMM slots (8 memory channels) Supporting up to 4TB RAM (Assuming 8x512GB DIMMs) 512GB DIMM support is stretch goal but may not be validated until requested PCIe Expansion Slots (4) PCIe Gen 5.0 x16 slots (All lanes from the CPU so
