Asus Crosshair VI Hero (90MB0SC0-M0EAY0)
 |
Asus Crosshair VI Hero
Towards:gaming
Form Factor:ATX
Socket:AM4
Chipset:AMD X370
BIOS:Ami
RAM slots:DDR4 4 sl
RAM form factor:DIMM
RAM clock:3200 MHz
Sound (channels):7.1
Connectors:M.2
Power connector:24-pin
Processor power:8+4-pin
Top 2017 Asus overclocker motherboard for AMD AM4 platform. Based on the X370 chipset, it is fully compatible with all 1st and 2nd generation 2, 4 and 8 core Ryzen/Ryzen Pro processors, A-series hybrid models (7th generation), and so on. same CPU Athlon X4 AM4 and Athlon 200GE. Equipped with the most powerful 12-phase processor power subsystem. It has an impressive array of overclocking features and great outdoor bench options.
An additional (second) clock generator and a high discreteness of the processor multiplier (0.25) are provided. Motherboard Asus Crosshair VI Hero is capable of working with water and cryogenic cooling systems. It is positioned as a premium product of the highest price category. Primarily intended for enthusiasts who want to get the maximum level of performance by using non-standard modes of operation of key system components. It can also become the basis for top gaming systems, including Nvidia 2-Way SLI and AMD 3-Way CrossFireX multiGPU configurations. Supports up to 64GB DDR4 RAM. Equipped with an Intel I211-AT gigabit network controller and high-quality ROG SupremeFX audio subsystem.
All specifications
Specifications Crosshair VI Hero
|
| |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
The information in the model description is for reference purposes.
Always clarify the specifications and configuration of the product with the online store manager before purchasing.
Catalog Asus 2026 - new arrivals, bestsellers, and the most relevant models Asus.
Always clarify the specifications and configuration of the product with the online store manager before purchasing.
Catalog Asus 2026 - new arrivals, bestsellers, and the most relevant models Asus.
Series Asus ROG Crosshair (gaming)Compare using chart →
ATX, socket AM5, chipset AMD X870E, 4 x DDR5, DIMM, 9600 MHz, USB-C, USB4, HDMI, M.2, LAN 10 Gbps, Wi-Fi, M.2 cooling
E-ATX, socket AM5, chipset AMD X870E, 4 x DDR5, DIMM, 9600 MHz, USB-C, USB4, M.2, LAN 10 Gbps, Wi-Fi, M.2 cooling, White Edition
micro-ATX, socket AM5, chipset AMD X670E, 2 x DDR5, DIMM, 6400 MHz, USB-C, USB4, DisplayPort, M.2, LAN 2.5 Gbps, Wi-Fi, M.2 cooling
ATX, socket AM5, chipset AMD X870E, 4 x DDR5, DIMM, 8200 MHz, USB-C, USB4, HDMI, M.2, SAS, LAN 5 Gbps, Wi-Fi, M.2 cooling
ATX, socket AM5, chipset AMD X870E, 4 x DDR5, DIMM, 8600 MHz, USB-C, USB4, HDMI, M.2, SAS, LAN 5 Gbps, Wi-Fi, M.2 cooling
mini-DTX, socket AM4, chipset AMD X570, 2 x DDR4, DIMM, 4800 MHz, USB-C, M.2, LAN 2.5 Gbps, Wi-Fi, M.2 cooling
E-ATX, socket AM5, chipset AMD X670E, 4 x DDR5, DIMM, 6400 MHz, USB-C, USB4, M.2, > 4 SATA3, LAN 10 Gbps, Wi-Fi, M.2 cooling
E-ATX, socket AM5, chipset AMD X870E, 4 x DDR5, DIMM, 9000 MHz, USB-C, USB4, HDMI, M.2, SAS, LAN 10 Gbps, Wi-Fi, M.2 cooling
ATX, socket AM5, chipset AMD X870E, 2 x DDR5, DIMM, 9600 MHz, USB-C, USB4, DisplayPort, M.2, LAN 5 Gbps, Wi-Fi, M.2 cooling
ATX, socket AM4, chipset AMD X370, 4 x DDR4, DIMM, 3200 MHz, USB-C, M.2, > 4 SATA3, SLI, CrossFire, suitable for mining
E-ATX, socket AM4, chipset AMD X370, 4 x DDR4, DIMM, 3200 MHz, USB-C, M.2, > 4 SATA3, SLI, CrossFire, Wi-Fi, M.2 cooling, suitable for mining
ATX, socket AM4, chipset AMD X470, 4 x DDR4, DIMM, 3466 MHz, USB-C, M.2, > 4 SATA3, SLI, CrossFire, M.2 cooling, suitable for mining
ATX, socket AM4, chipset AMD X470, 4 x DDR4, DIMM, 3466 MHz, USB-C, M.2, > 4 SATA3, SLI, CrossFire, Wi-Fi, M.2 cooling, suitable for mining
ATX, socket AM4, chipset AMD X570, 4 x DDR4, DIMM, 4800 MHz, USB-C, M.2, > 4 SATA3, LAN 5 Gbps, SLI, CrossFire, Wi-Fi, M.2 cooling
ATX, socket AM4, chipset AMD X570, 4 x DDR4, DIMM, 5100 MHz, USB-C, M.2, > 4 SATA3, LAN 2.5 Gbps, SLI, CrossFire, Wi-Fi, M.2 cooling
ATX, socket AM4, chipset AMD X570, 4 x DDR4, DIMM, 5100 MHz, USB-C, M.2, > 4 SATA3, LAN 2.5 Gbps, SLI, CrossFire, M.2 cooling
ATX, socket AM4, chipset AMD X570, 4 x DDR4, DIMM, 5100 MHz, USB-C, M.2, > 4 SATA3, LAN 2.5 Gbps, SLI, CrossFire, Wi-Fi, M.2 cooling
E-ATX, socket AM4, chipset AMD X570S, 4 x DDR4, DIMM, 5100 MHz, USB-C, DisplayPort, Thunderbolt v4, M.2, > 4 SATA3, LAN 10 Gbps, SLI, Wi-Fi, M.2 cooling
ATX, socket AM5, chipset AMD X670E, 4 x DDR5, DIMM, 6400 MHz, USB-C, USB4, HDMI, DisplayPort, M.2, > 4 SATA3, LAN 2.5 Gbps, Wi-Fi, M.2 cooling
AccessoriesAll accessories for Asus Crosshair VI Hero →
the mother is enough to keep 4GHz on the ryzen 1700 without problems, quite a good mother, but not worth the money, it makes sense to buy only if it is cheaper than the new asrock taichi. 12 phases, not 16 for asrock. Power 8 + 4 is not needed, 8 pin is enough VRM does not overheat, a lot of functionality Developers sometimes release BIOS curves, the interface is not immediately clear, it will take time to figure it out (in my case it was like that), the MSI BIOS interface is the most convenient on the x370 use Asus Crosshair VI Hero few months |
Take if you have enough money A very, very good mother, the best money can buy. It's easy to drive ryzen on it, memory. In the settings, set the multiplier and that's it))) you can do it like that, I have 1800x keeps 4.0 GHz with a maximum temperature of 70 degrees with air from msi, with manual settings I lowered the voltage from 1.4 to 1.385 and won only 2 degrees during stress tests. Meals for 8 + 4 percent. I have only 8)) I had to buy an adapter from the Molex  Vladimir Shiller: use Asus Crosshair VI Hero month or more i recommend it should buy |
Add Review
Video reviews
ASUS Crosshair VI Hero X370 VRM Analysis with Buildzoid
3 March 2017107 254 view
Asus Crosshair VI Hero Review - The best Ryzen AM4 motherboard?
4 March 2017100 813 view
Crosshair VI Hero Unboxing and First Look
17 February 201781 600 view
Ryzen 7 1800X Build - ASUS CROSSHAIR VI HERO / BitFenix Shogun (Livestream)
29 March 201771 349 view
ASUS ROG Crosshair VI Hero BIOS Overview
6 April 201731 107 view
Asus x370 Crosshair VI Hero Ryzen Motherboard Review
15 July 201713 896 view
The BEST for RYZEN? - ASUS Crosshair VI Hero Review
25 April 201711 368 view
ITS AMAZING! - ASUS Crosshair VI Hero X370
29 March 20178 095 view
ASUS ROG CROSSHAIR VI HERO X370 Motherboard Review - The Best AMD Ryzen Motherboard?
1 April 20176 648 view
EK-FB ASUS C6H RGB Monoblock - Nickel Unboxing (Crosshair VI Hero)
13 August 20172 217 view
CROSSHAIR VI Hero Complete Review
7 June 20172 055 view
ASUS Crosshair VI Hero Review - 1 month after purchase - Let's Take a look
14 May 2017778 view
Unboxing Asus Crosshair VI HERO [X370] RYZEN
30 March 2017451 view
2017 New AMD !!ASUS ROG CROSSHAIR VI HERO AMD Motherboard Full Review
28 April 2017288 view
Additional features motherboard Asus Crosshair VI Hero:
- Rear BIOS and clear CMOS buttons
