Gigabyte X570S AORUS MASTER
 |
 |
Close
Gigabyte X570S AORUS MASTER
Towards:gaming
Form Factor:ATX
Socket:AMD AM4
Chipset:AMD X570S
BIOS:Ami
RAM slots:DDR4 4 sl
RAM form factor:DIMM
RAM clock:5400 MHz
Sound (channels):7.1
Connectors:M.2
Power connector:24 pin
Processor power:8+8 pin
A high-end motherboard from Gigabyte that stands out even from its Aorus counterparts. It belongs to the highest price segment and is designed for demanding gamers and overclocking enthusiasts who are looking for the ultimate solution capable of solving problems of any complexity. Up to overclocking a hot and voracious Ryzen 9-level processor. Especially for such tricks, it was equipped with the flagship AMD X570S chipset and an advanced 16-phase power subsystem with a high-end element base and ubiquitous cooling of power circuits.
As Gigabyte boasts, this is the first motherboard in the world to use Infineon TDA21472 MOSFETs, each of which is capable of withstanding up to 70A of current, which in total gives a whopping bandwidth of around 1120A. In all other respects, the Gigabyte X570S AORUS MASTER gentleman's set fully corresponds to the price and status of this board. It includes several M.2 ports with cooling and support for the PCI-E 4.0 bus, 2 video card slots, 4 DDR4 RAM slots with a maximum clock speed of 5400 MHz, and a top-end Realtek ALC1220-VB audio path. Additional trump cards in her hands were a wireless receiver (Wi-Fi 6 + Bluetooth 5.2), an advanced Intel 2.5GbE network controller, as well as numerous connectors for LED strips, liquid cooling systems, Thunderbolt modules, etc.
All specifications
