Gigabyte X299 UD4 Pro
 | $534.00 Buy!  Gigabyte Intel X299 UD4 Pro Socket LGA 2066 DDR4 ATX Motherboard (X299 UD4 PRO)Newegg.comDelivery: in USA Report |
 |
Close
Gigabyte X299 UD4 Pro
Form Factor:ATX
Socket:Intel LGA 2066
Chipset:Intel X299
BIOS:Ami
RAM slots:DDR4 8 sl
RAM form factor:DIMM
RAM clock:4400 MHz
Sound (channels):7.1
Connectors:M.2
Power connector:24 pin
Processor power:8 pin
Full size ATX form factor motherboard with Intel X299 chipset and LGA 2066 processor socket for Intel HEDT (High-End Desktop) processors. Fully supports Intel Core X-series i9/i7/i5 CPU based on Skylake-X, Kaby Lake-X and Cascade Lake-X microarchitecture. With up to 18 active cores, these processors represent the highest performing top-end Intel desktop processors of 2017. It is positioned as a product of the upper price category, focused on creating performant workstations.
Thanks to five full-size PCI-E Gen 3.0 x16 slots, it is possible to create top-end multiGPU configurations using Nvidia Quad-GPU SLI and AMD 3-Way CrossFireX technologies. The overclocking functionality and powerful power converter of the Gigabyte X299 UD4 Pro motherboard will interest enthusiasts. The available eight slots for installing DDR4-2666 RAM modules (up to 4400 MHz in overclocking) can operate in 2-channel (4-Core CPU) or 4-channel mode (6/8/10-Core CPU). Two full-speed M.2 ports and eight SATA3 connectors allow you to create a fast and capacious storage subsystem. The built-in Intel gigabit controller is responsible for transmitting network traffic. The processing and output of high-quality sound is carried out by the top Realtek ALC1220 audio codec with an improved analogue path and an optical S / P-DIF output.
All specifications
Specifications X299 UD4 Pro
|
| |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
