Asus TUF Gaming BE6500 (90IG0920-MO9C00)

Photos - Wi-Fi Adapter Asus TUF Gaming BE6500
Photos 5
Compare prices 2 →
When you make a purchase through links on our site, we may receive a affiliate commission.
 $157.98  $210.00
add to listmy lists
Asus TUF Gaming BE6500
WAN:Ethernet, 4G LTE over USB, 3G via USB
Connection:LAN 3 ports, 2.5 Gbps
Wi-Fi:Wi-Fi 7 (BE)
2.4 GHz:688 Mbps
5 GHz:5764 Mbps
Antennas and signal:MU-MIMO, 6 antenna(s), non-removable
AiProtection Pro — Asus network protection system. Gaming port for prioritizing gaming traffic. High-performance processor and large amount of memory for seamless operation even under heavy load.

High-performance wireless dual-band gaming router (router) of 2024 with support for Wi-Fi 7 standard (802.11n/ac/ax/be), powerful quad-core processor, high-speed USB 3.2 Gen1 port, and 160 MHz bandwidth. In addition to the 4x4 MU-MIMO multi-thread data transfer technology, it supports the intelligent bandwidth aggregation technology of both bands (Multi-Link Operation).

Thanks to this, the Asus TUF Gaming BE6500 router is capable of providing ultra-fast data transmission (class BE6500) and ultra-low latency for comfortable gaming in any modern gaming projects and esports disciplines. It is also worth noting the original exterior design with six external antennas. Positioned as a high-end product of 2024, designed for creating high-performance wireless and wired networks with low latency in apartments, private homes, or small offices.

To create an incoming connection to the provider's network, you can use the 2.5-GbE WAN port. Thanks to the powerful hardware platform with a quad-core ARM processor, this router delivers ultra-high theoretical throughput with low latency. However, approaching such speeds in practice is only possible when using client devices that support the 4x4 MU-MIMO mode, 160 MHz wide channels, OFDMA channel frequency division, and 4096-QAM modulation.

All specifications
Specifications TUF Gaming BE6500
Colour
Product typegaming router
Data input (WAN-port)Ethernet (RJ45)
Wi-Fi
3G modem (USB)
4G (LTE) modem (USB)
Wireless Wi-Fi connection
Wi-Fi standardsWi-Fi 3 (802.11g)
Wi-Fi 4 (802.11n)
Wi-Fi 5 (802.11ac)
Wi-Fi 6 (802.11ax)
Wi-Fi 6E (802.11ax)
Wi-Fi 7 (802.11be)
Frequency band2.4GHz
5 GHz
Operating rangesdual-band (2.4 GHz and 5 GHz)
Wireless speed 2.4 GHz688 Mbps
Wireless speed 5 GHz5764 Mbps
Bandwidth160 MHz
Connection and LAN
WAN1 port
2.5 Gbps
LAN3 ports
2.5 Gbps
USB-A 5Gbps1 pcs
Antenna and transmitter
Number of antennas6
Antenna typeexternal
MU-MIMO
2.4 GHz antennas2
5 GHz antennas4
Hardware
CPU cores4
Clock Speed1.5 GHz
RAM1 GB / DDR4 /
Flash memory256 MB
Functions
FeaturesNAT
repeater
MESH mode
Beamforming
firewall
CLI (Telnet)
More featuresDHCP server
FTP server
file server
media server (DLNA)
torrent client
VPN
DDNS
DMZ
Security
Safety standardsWPA
WEP
WPA2
WPA3
802.1x
General
Operating temperature0 °C ~ +40 °C
Dimensions304x174x214 mm
Weight772 g
Official Websiteasus.com
Added to E-CatalogNovember 2024
P/N
90IG0920-MO9C00

The information in the model description is for reference purposes.
Always clarify the specifications and configuration of the product with the online store manager before purchasing.
Catalog Asus 2026 - new arrivals, bestsellers, and the most relevant models Asus.
For me, ASUS TUF Gaming BE6500 will become a further upgrade.
16 December 2025
I use this router as the main one in my apartment, where lots of devices are running simultaneously. After setting it up, the difference compared to the old device was noticeable right away. The connection is stable, and the speed doesn't drop even when everyone is using the internet at the same time.

The wireless network works reliably across the entire area; the signal doesn't disappear through walls. Online games run smoothly, and high-quality videos start quickly without buffering. Everything is also stable via cable, which is important with a high-speed provider.

I set it up myself without any outside help. The menu is clear, key parameters are easy to find, and there's the option to control traffic and create a separate network for guests. The router itself looks solid and well-built, it feels like a serious piece of equipment.
Stable operation without disconnections, good level of Wi-Fi signal, fast wired connection, easy setup.

Reliable casing
The full potential is only realized with modern devices.
Andriy Serdyukuse Asus TUF Gaming BE6500 less than month
Add Review

Stylish Gaming Gadget

The Asus TUF Gaming BE6500 router is part of the brand's gamer lineup, attracting attention with its expressive design and high performance. The device is built on a quad-core processor and equipped with 1 GB of RAM, which allows for effective load distribution when multiple dozens of users are working simultaneously, and minimizes delays in the transmission of large data, whether online games or 8K video streaming.

The chassis design is aimed at efficient heat dissipation, ensuring stable operation even under high load and during prolonged sessions.

Reception and Distribution

Wired capabilities are represented by WAN and LAN ports with a speed of 2.5 Gbps, providing very fast Internet access and data exchange within the home or office network. A dedicated gaming port with prioritized traffic is optimal for connecting consoles, gaming PCs, and laptops.

The model supports working with 3G and 4G modems, which can be used as a backup communication channel in case of failures with the main provider. Connection is made via USB 3.2 Gen1 port, which is also suitable for setting up a file server using external storage.

Among the key advantages is support for the Wi-Fi 7 standard with MLO technology, allowing multiple frequency bands to be used simultaneously. In this case, it’s 2.4 and 5 GHz with a combined speed of up to 6.5 Gbps, an impressive figure even by modern standards. Additionally, AiMesh mode is implemented for creating a seamless wireless network.

Software Support

The manufacturer has paid special attention to the software component. Convenience and simplicity of management are provided by the Smart Home Master function in the ASUS Router app, which also offers a mobile gaming acceleration mode.

The capabilities are enhanced by a three-level security system AiProtection, designed to protect the router itself, computers, and the most vulnerable devices, including smart home elements, appliances with remote control, and security systems. Users can diagnose the network, identify and eliminate vulnerabilities, block connections, limit traffic and content, and create secure guest zones.
