Marantz Model 70

Photos - Amplifier Marantz Model 70
Videos 3Photos 21
Expecting restock
Device type: integrated amplifier; Element base: transistor; Number of channels: 2; Frequency range (Hz): 5 — 100000; Power per channel, 8 ohms (W): 50; Power per channel, 4 ohms (W): 65; Signal to noise ratio (dB): 110; Signal-to-noise ratio (Phono MM/MC), dB: 83; Damping factor: 100
add to listmy lists
Marantz Model 70
Type:integral
Number of channels:2
Power per channel (8 ohms):50 W
Coef. damping:100
To amplifier (Main):RCA
Inputs:optical
RCA inputs:3 steam(а)
Outputs:Pre-Amp
All specifications
Specifications Model 70
Main
Device typeintegrated amplifier
Element basetransistor
Toroidal transformer
Amplifier parameters
Number of channels2
Frequency range5 — 100000 Hz / ±3 дБ /
Power per channel (8Ω)50 W
Power per channel (4Ω)65 W
Signal to noise ratio110 dB
Signal to noise ratio (Phono MM/MC)83 dB
Damping factor100
Harmonic distortion0.08 %
Connectors
InputsPhono
coaxial S/PDIF
optical
control input (IR)
To amplifier (Main)RCA
RCA3 pairs
OutputsPre-Amp
to subwoofer
control output (IR)
For acoustics4 шт
Front paneldisplay
headphone output
Features
Adjustmentsbass control
treble adjustment
balance adjustment
level adjustment
More featuresBy-pass/Direct
auto power off
ММ phono stage
Bi-Wiring
external devices control
General
Remote control
Chassis materialsteel
PSUinternal
Power consumption150 W
Standby consumption0.3 W
Dimensions (WxDxH)442x375x109 mm
Weight7.9 kg
Added to E-CatalogAugust 2026
The information in the model description is for reference purposes.
Always clarify the specifications and configuration of the product with the online store manager before purchasing.
