Kahles K525i 5-25x56 SKMR4 Right

Photos - Sight Kahles K525i 5-25x56 SKMR4 Right
Videos 2Photos 13
Outdated Product
Type: optic; Design: enclosed; Magnification (x): 5 – 25; Magnification adjustment; Lens diameter (mm): 56; Reticle: in the 1st focal plane (FFP); Aiming mark illumination; Backlight brightness adjustments; More features: dust-, waterproof; shockproof; nitrogen filled; Elevation drum: open
add to listmy lists
Kahles K525i 5-25x56 SKMR4 Right
Kahles K525i 5-25x56 SKMR4 Right
Type:optic
Magnification:5 – 25 x
Lens diameter:56 mm
Field of view at 100 m:7.1 – 1.5 m
Scope length:377 mm
All specifications
Specifications K525i 5-25x56 SKMR4 Right
Main
Typeoptic
Designenclosed
Optical characteristics
Magnification5 – 25 x
Magnification adjustment
Lens diameter56 mm
Exit pupil diameter9.5 – 2.3 mm
Offset of the exit pupil95 mm
Field of view at 100 m7.1 – 1.5 m
Twilight factor16.7 / 37.4 /
Measuring units of the sightMRAD
Adjustment division value0.1 MRAD
Parallax adjustmentside drum (SF)
Diopter adjustment / -3.5 to +2 /
Zero setting
Lens coatingfull multilayer enlightenment
Aiming mark
Reticlein the 1st focal plane (FFP)
Reticle typeherringbone / SKMR4 /
Reticle measuring unitsMRAD
Aiming mark illumination
Backlight brightness adjustments
More features
More featuresdust-, waterproof
shockproof
nitrogen filled
Elevation drumopen
Power source
Power sourceCR2035
General
Weapon compatibilitylarge-caliber
Mounting ring diameter34 mm
Materialmetal
Country of originAustria
Sight length377 mm
Weight970 g
Official Websitekahles.at
Added to E-Catalogfebruary 2024
Information in model description is for reference purposes.
Before buying always check characteristics and configuration of product with online store manager
