Portable low-voltage uninterruptible power supply (UPS) with a wide range of output ports (2xUSB, 3xDC-output, PoE LAN) and support for the cold start function to start de-energized devices. It is distinguished by its modest weight (380 g) and small dimensions (4.8x14.6x5.1 cm). The device is equipped with four built-in Li-Ion batteries with a total capacity of 10400 mAh (4x2600 mAh) and this capacity is enough to provide 7 hours of autonomous operation of the client device with a consumption of 5 V (the typical consumption of a simple Wi-Fi router is 3-4 W). The YEPO UA-112485 portable uninterruptible power supply is positioned as a product of the basic price category of 2024, focused on home/professional use. The peak power of such a UPS can reach 24 W, the long-term declared power is 18...W. It is equipped with three standard DC connectors capable of operating in 5V/2A, 9V/1A and 12V/1A modes. In addition, there are USB A 5V/2A, USB C 5V/3A connectors and two Ethernet ports for supplying power at 15V/0.6A and 24V/0.4A using Power-over-Ethernet technology. Such an uninterruptible power supply can provide backup power for various low-voltage network devices, including routers, Wi-Fi access points, radio stations, CCTV cameras and LED lighting. It can effectively charge smartphones and tablets. The uninterruptible power supply itself can be charged from a network with a voltage of 100 to 240 V.
add to listmy lists
YEPO UA-112485
Main
Typelow voltage UPS (router, camera)
Form factorstandard (flat)
Full load operating time480 min
Input
Input voltage1 phase (230V)
Input voltage range100 – 240 V
Bypass (direct connection)is absent
Output
Output voltageDC (constant voltage)
Rated output power18 W
Output waveformpure sine wave (PSW)
Charging USB A ports1 / 5 H 2A /
USB-C for charging1 pcs / 5 H 3A /
Battery
Total battery capacity10.4 Ah
Number of batteries1
Battery typeLi-ion (lithium-ion)
Cold start
Protection
Protectionshort circuit protection
overload protection
noise filtering
General
Operating temperature0 – 45 °C
Dimensions (HxWxD)48x146x51 mm
Weight0.38 kg
Added to E-Catalogjuly 2024

Portable low-voltage uninterruptible power supply (UPS) with a wide range of output ports (2xUSB, 3xDC-output, PoE LAN) and support for the cold start function to start de-energized devices. It is distinguished by its modest weight (380 g) and small dimensions (4.8x14.6x5.1 cm). The device is equipped with four built-in Li-Ion batteries with a total capacity of 10400 mAh (4x2600 mAh) and this capacity is enough to provide 7 hours of autonomous operation of the client device with a consumption of 5 V (the typical consumption of a simple Wi-Fi router is 3-4 W).

The YEPO UA-112485 portable uninterruptible power supply is positioned as a product of the basic price category of 2024, focused on home/professional use. The peak power of such a UPS can reach 24 W, the long-term declared power is 18 W. It is equipped with three standard DC connectors capable of operating in 5V/2A, 9V/1A and 12V/1A modes. In addition, there are USB A 5V/2A, USB C 5V/3A connectors and two Ethernet ports for supplying power at 15V/0.6A and 24V/0.4A using Power-over-Ethernet technology. Such an uninterruptible power supply can provide backup power for various low-voltage network devices, including routers, Wi-Fi access points, radio stations, CCTV cameras and LED lighting. It can effectively charge smartphones and tablets. The uninterruptible power supply itself can be charged from a network with a voltage of 100 to 240 V.
