Marstek V500

Photos - Inverter Marstek V500
Videos 3Photos 13
Expecting restock
Device type: hybrid inverter; In box: with battery pack; Network type: 1 phase (230 V); Rated power (kW): 0.5; Connection voltage (V): 3.2; Controller: 1xMMPT; UPS function; Bluetooth; Wi-Fi; Dimensions (mm): 220x206x290; Weight (kg): 15.5;
E-Catalog uses affiliate links compensated by our partners.
Find prices on Amazon.com
Find prices on eBay.com
add to listmy lists
Marstek V500
+ batteryUPSMPPT-t °CWi-Fi
Main
Device typehybrid inverter
In boxwith battery pack
Network type1 phase (230 V)
AC output
Rated power0.5 kW
Peak power1 kW
Rated AC current2.2 A
Maximum AC power2.4 А
Output waveformpure sine
Number of sockets1
Batteries and DC charging
Connection voltage3.2 В
Total battery capacity628 Ah / 2x314 Ач /
Total battery capacity2009 Wh / LiFePO4 /
Solar PV panels
Max. power0.5 kW
Operating voltage PV12 – 60 В
Controller1xMMPT
Features and control
FunctionsUPS function
Control interfacesBluetooth
Wi-Fi
Protectionshort circuit protection
↑ or ↓ battery voltage protection
overload protection
overheat protection
General
Displayin absent
Coolingpassive
Noise level30 dB
Casing protection classIP65
Operating temperature-10 °C ~ +50 °C
Dimensions (HxWxD)220x206x290 mm
Weight15.5 kg
Official Websiteeu.marstekenergy.com
Added to E-CatalogJuly 2026
Operates on a Plug & Play basis. Input power from the mains: 750 W.
The information in the model description is for reference purposes.
Always clarify the specifications and configuration of the product with the online store manager before purchasing.
How to choose a solar inverterTypes of inverters for solar power generation systems and the fundamental parameters for their selection
AccessoriesAll accessories for Marstek V500 →
User reviews 1
Write Review →
great model, really liked it
Yesterday
Great option for winter outages to power the most essential devices at home. 500 W + a 2 kWh battery provide 10+ hours of refrigerator operation or around 18 hours of normal PC use. Nothing extra: one socket and several charging ports. Yes, there are no USB ports, but I did not need them when choosing a backup power source. Charges from 0 to 100% in about 4 hours. Draws 500 W while charging.
Minimalism, excellent battery capacity, convenient phone app
Not detected yet
Kyrylo Husiev: use Marstek V500 less than month
