LONGi LR7-72HVH-645M 645 W

Photos - Solar Panel LONGi LR7-72HVH-645M 645 W
Photos 4
Outdated Product
Features: stationary; Type: monocrystalline; STC Power (Pmax) (W): 645; Nominal voltage (Vmp): 44.46; Nominal power (Imp) (A): 14.51; Open-circuit voltage (Voc) (V): 53.8; Short circuit current (Isc) (A): 15.21; Efficiency (%): 23.9; USB-A: USB-C: MC4 connector; Dimensions (mm): 2382x1134x30
E-Catalog uses affiliate links compensated by our partners.
Find prices on Amazon.com
Find prices on eBay.com
add to listmy lists
LONGi LR7-72HVH-645M 645 W
630 W
635 W
640 W
645 W
650 W
Main
Featuresstationary
Typemonocrystalline
Specs (STC)
STC Power (Pmax)645 W
Nominal voltage (Vmp)44.46 В
Nominal power (Imp)14.51 А
Open-circuit voltage (Voc)53.8 В
Short circuit current (Isc)15.21 А
Efficiency23.9 %
Specs (NOCT)
NOCT Power (Pmax)491 W
Rated voltage (Vmp)42.25 В
Rated current (Imp)11.63 А
Open circuit voltage (Voc)51.13 В
Short circuit current (Isc)12.22 А
Features
MC4 connector
WaterproofIP68
Operating temperature-40 °C ~ +85 °C
General
Number of cells144 (6x24)
Dimensions2382x1134x30 mm
Weight28.5 kg
Added to E-CatalogAugust 2025
The information in the model description is for reference purposes.
Always clarify the specifications and configuration of the product with the online store manager before purchasing.
